The castings have large grains, and I will give you some practical suggestions!

Views: 1028 Update date: Oct 14,2021



1 Casting structure and process design

(1) If the cross-section difference of the casting is too large, the thicker cross-section will cool slowly and cause the coarse grains there. Metals, such as gray cast iron, which are very sensitive to cross-sectional changes, are more likely to produce such defects. An effective way to prevent such defects is to avoid excessive disparity in the cross-sectional dimensions of castings, but this approach is sometimes beyond the reach of foundry workers. Therefore, as far as casting itself is concerned, it is possible to reduce the occurrence of such problems and the severity of such defects by setting cold iron, controlling the pouring temperature, or selecting a suitable pouring system. The use of cold iron can speed up the cooling rate of the thicker section of the casting; too high pouring temperature will make this kind of problem more serious and should be avoided; by adjusting and revising the pouring system design, the lower temperature of the molten metal is located at the lower section of the casting. Thick parts, and design the most effective riser at the thick section of the casting to reduce the size of the riser as much as possible.

(2) For castings with holes, process designers sometimes do not use cores that help reduce the effective cross-sectional size, and make the cross-sections without cores too thick to cause this defect. Therefore, in process design, it should be as small as possible. A sand core is set in the thick section.

(3) In some cases, the section of the casting is not too thick, but because a narrow recess or core forms a heat sink section in the casting, the result is the same as the thick section. E.g. It may be necessary to set a core at a columnar umbilicus in the deeper part of the casting, and this will cause slow cooling. In the case that the design cannot be modified, unless the metal temperature can be lowered, or the gate can be relocated, the best solution is to install cold iron at the core or mold section.

(4) The machining allowance is too large in the process design, which not only increases the cost of cutting, but also cuts off the denser surface of the casting, and exposes the loose part with slower cooling in the center. This design is undesirable because it is unreasonable from the perspective of casting or machining. The solution is to change the design of the casting. If the design is not allowed to change, the correct method is to use cold iron, control the pouring temperature and adjust the pouring system.

(5) Inappropriate core design at the thick section, incorrect core support, or other technologies that cause eccentricity, will cause changes in the section of the casting and cause coarse grains.


2 pouring riser system

(1) Failure to achieve sequential solidification" The failure of the pouring system to achieve sequential solidification well is usually the cause of coarse grains. For castings with sharp cross-section changes, attention must be paid to the number and location of the gate. In order to perform feeding, keeping hot molten metal in the action area of the feeder will reduce the cooling rate of the thick section to the extent that coarse grains are produced. Improper riser design, such as too long riser neck, improper riser pad design, or too large riser size, will cause excessive heat collection at the thicker section.

(2) Pouring riser distribution that is likely to cause heat sinks. Similarly, in order to feed thick sections, excessive heat collection is often caused in local areas. For example, because the side riser can cause overheating of thick sections and slow down the cooling rate, it is sometimes inconvenient to use in actual operation. In actual production, a reasonable riser design is required to reduce the size of the riser as much as possible.

(3) The connection between the inner gate or the riser and the casting causes the local hot joint. The inner gate or the riser neck is short, which is beneficial for feeding, but it will make the runner or riser too close to the casting. Slow down the cooling rate of this part. Enlarging the neck of the riser will cause problems for feeding. Therefore, the best measure is to adopt an effective riser design, reduce the size of the riser as much as possible, do not make the runner and the riser too close to the key section that is easy to form a coarse product, and set the runner and the riser appropriately. To achieve feeding.

(4) Insufficient number of internal gates. Too few internal gates will not only easily cause sand washing, but also cause local hot spots and coarse grain structure. This phenomenon is common in all cast metals, even aluminum alloys with lower casting temperatures. In some cases, because the number of gates is too small, it will cause shrinkage defects. This shrinkage defect may conceal the coarse grain defects caused by the same reason. In fact, when the coarse grain defect deteriorates seriously, it becomes a shrinkage defect. Therefore, the prevention and control measures for these two types of defects are often the same.


3 sand

Only when the displacement of the molding wall caused by the molding sand is sufficient to increase the cross-sectional size of the critical section (the section that is easy to form coarse grains), the mold sting is a factor that causes the coarse grain defects. Since the wall movement at the thick section may be the largest, this kind of defect is still possible, and the coarse grain defect produced at this time is related to the expansion of sand.


4 core

In production, the use of unbaked or air-hardened oil sand cores should be avoided, because such cores may produce exothermic reactions and cause excessive heat collection. This happens either in large castings, or in thick and large cores using adhesives with exothermic properties. In a sense, this core acts as a highly efficient insulator and slows down the cooling rate of molten metal to a dangerous level.


5 styling

(1) Lack of vent holes that can accelerate the cooling rate. For thicker casting sections, the cooling rate of the casting is related to the rate of heat dissipation through the molding sand. Adequate exhaust will help the water vapor to be expelled quickly, thereby producing a cooling effect.

(2) The absence of chill nails or cold iron is usually caused by carelessness.


6 chemical composition

Essentially, the coarse crystal grains and the chemical composition of the metal are related to the cooling rate, so it is very important to choose this combination. If the cooling rate is difficult to adjust, then the coarse-grained structure must be due to the improper chemical composition of the metal. Due to the importance of metal components, each metal is briefly described as follows.

(1) Gray cast iron and malleable cast iron

If the carbon equivalent is too high, the mathematical calculation of carbon and silicon effects can usually be summarized as: CE=C+1/3Si. The coarse grains may be caused by excessive carbon or silicon, or carbon and silicon. Compared with silicon, the effect of carbon is three times that of silicon, so the change in the amount of carbon is much more dangerous than the change in the same amount of silicon. This effect of carbon and silicon affects both malleable cast iron and gray cast iron. For malleable cast iron, the coarse grains do not appear as black, nor do they appear as pits that indicate virgin graphite, but in the form of general coarse grains. This is due to the high carbon or silicon content, or Both are too high. Phosphorus also affects the coarseness of crystal grains. When wp=0.1%, the shrinkage cavity defect will be aggravated, especially the degree of coarse grain defects in the section where the cooling is slower.

(2) Cast steel

In the melting and deoxidation operations of cast steel, some elements that delay the growth of grains are added. Therefore, compared with forged steel, cast steel is less likely to form coarse grains. Steel castings with coarse grains caused by composition can be refined by annealing or normalizing.

(3) Aluminum alloy

Iron impurities will make aluminum castings coarser grains and increase brittleness. Most of these defects are caused by improper melting operations. In aluminum alloys, especially those requiring overheating, it is necessary to add an appropriate amount of refined alloy elements.

(4) Copper alloy

Coarse grain defects in copper alloys are often covered by pinholes, pores or shrinkage. Copper alloys will cause coarser grains due to changes in composition, but usually pinholes, pores or shrinkage porosity always appear first.
